SKYRC T6755 Charger

Some time ago in racing competition I won charger for lipos and others type of batteries manufactured by SKYRC.

Inside package we have manual instruction in English.

Specification:

AC input: 100-240V AC

DC Input: 11-18 V

Charge circuit power: 55W

Charge current range: 0,1-7A

Discharge current power: 5W

Net weight: 540g

Dimensions: 140x165x60mm

Charger

Cables to AC 100-240V, multiple balancing board, 18 AWG wire charging cable



 On the left side have DC Input 11-18A AC, balance socket, battery socket, usb port for PC control & firmware upgrade and temperature probe socet (probe is not included in this standard package)

 And HOME menu to change between LiPo/Li-Ion/LiFe/NiCd/MiMH/PB and operation (not for all types of batteries) CHARGE/DISCHARGE/STORAGE/FAST CHARGE/ BAL CHARGE/VOLT METER/ CYCLES/RE-PEAK/ AUTO CHARGE.

 I'm using lipos in my miniquads so how i set my charging/discharging ?
Start from cells : 2/3/4s up to 6s can be set.

 Now set capacity and maxiumum current, discharge current.

 In third button we have system setting

 We can change colour, buzzer (for me is to noiseless) LCD light

 In next section we have safety protection values

 Charger parameters (for example the max value for lipo 4,2V default can be change 4,1V/ cell)

 In preset we can set 6 parameters of operation (save a cells/current etc. )

 If we are all setting done we can charge our lipos, klick only triangle in right corner

During charging process we can check graph of charging/discharging in time, resistance of battery. Shown minimum and maximum voltage at cells

My observation:

- sound is to noiseless (i have comparison to turnigy accuel 6 and turnigy is much louder),

- build in feeder, and have xt60 socket for for example car battery power supply,

- 55W for me it isnt enough, if i charge 6 lipos 3s i can only max 4,4A have (0,73A/ battery) for 4s is even less.

Its nice touchable charger but if i would to buy this i take more powerful.
